The NC Sensor uses SEMITEC’s ultra-small FT thermistors as temperature sensing elements to create an IR sensor that can be used in many different locations and formerly impossible environments. SEMITEC’S NC sensor is fully compliant with RoHS DIRECTIVE2011/65/EU.
Office automation fuser roler applications such as LBP, PPC etc.
Rotating parts in automotive applications.
Rotating motor parts
Temperature measurement in high pressure environments
Temperature measurement of drugs and chemicals
| Parameters | Value | Conditions |
|---|---|---|
| Measurement center | 180℃±3℃ | Blackbody temp.: 180℃; sensor body temp.: 100℃ |
| Roller diameter: 40 mm; distance: 5 mm | ||
| Responsivity | 1.3s±0.5s | Time required to reach 63.2% of temperature difference between blackbody and sensor body. |
| Operating temp. range | -10℃〜-150℃ | ― |
| Measuring temp. range | -20℃〜260℃ | ― |
| Thermistor resistance value | 7kΩ±3% | Rated zero-power resistance at 180℃ |
| Thermistor B-value | 3370K±1% | B-value determined by rated zero-power resistance at 25℃ and 85℃ |
